Description

Electrical Specifications

• Input Current Impedance: ≤ 0.01 Ω
• Rated Output Voltage: 200 V – 240 V

Current Ratings

• Rated Operating Current (25°C): ≤ 60 A (Continuous)
• Single-Channel Operating Current (25°C): ≤ 13 A (Continuous)
• Single-Channel Peak Current: ≤ 30 A

Power

• Power Consumption: ≤ 8 W

Performance

• Channel Switching Time: 1 Second
• Indicator: Each Channel Has Independent Switching Indicator

Mechanical

• Equipment Frame Height: 1U (Complies with International Installation Standards)

Dimensions

• Unit Dimensions (W × D × H):
  • 483 mm × 280 mm × 55 mm
  • 483 mm × 260 mm × 46 mm
• Packaging Dimensions (W × D × H):
  • 545 mm × 328 mm × 100 mm

Weight

• Net Weight: 3.4 kg
